The job information (Standard information, Control information and Detail information) can be changed while the status of each job nets and its jobs remain. The following describes how to do so.
Job information that can be changed
The job information that can be recovery-changed is the information that can be registered in the Add/Change - Job window.
The following information, however, cannot be changed.
The recovery job cannot be changed to the ordinary job. Therefore, the Recovery checkbox is grayed out in the Control information sheet of Add/Change - Job window. The Restart previous job check box can be changed.
Wait for preceding job using OR condition in the Control information tab of the Add/Change Job window cannot be changed.
For jobs with the job net or linked job net icon, the job net name cannot be changed. Therefore, Job Net List is not displayed in the Standard information sheet of the Add/Change - Job window, and the job net name and the job net comment is displayed in text.
Valid only on startup days specified for a child or linked job net cannot be changed. The Valid only on startup days checkbox in the Control information sheet of the Add/Change - Job window is grayed out.
Procedure
The following gives the procedure.
Displaying the Recovery Change Job Net window
Select Change Recovery from the File menu of Monitor Job Net window.
The Monitor Job Net window will change to the Recovery Change Job Net window.
Figure 4.60 Recovery Change Job Net window
Displaying the Add/Change-Job window
Display the Add/Change-Job window by performing one of the following operations.
Select the job you want to change, then select Properties from the File menu.
Select the job you want to change, then select Properties from the pop-up menu displayed by right-clicking.
Double-click the job you want to change.
Changing the job information
Change the job information in the Add/Change-Job window.
Saving the changes
Select Save from the File menu.
The job property information is changed without changing the status of the job net and its jobs.
Exiting from the Recovery Change Job Net window resumes the Monitor Job Net window.
Note
When the job net is under execution, you cannot overwrite it in the Recovery Change Job Net window. If the job net is under execution, an error message will be output.
When the information is saved in the Recovery Change Job Net window, the temporary change information of all the jobs in the job net will be deleted.
