PRIMECLUSTER Global Disk Services Configuration and Administration Guide 4.1 (Linux)

5.5.4 Removing a Class

Removing all disks within a class will automatically remove the class.

The procedure is explained below.



1. Removing all groups within the class

   Remove all groups within the class by following the procedure described in "Removing a Group."




2. Removing all disks from class

   Disconnect all disks by following the procedure below.

   (1) Displaying Class Configuration screen

   In the main screen [Settings] menu, select [Class Configuration]. The Class Configuration screen appears.

   (2) Selecting class to remove

   Select the class you want to remove from Class Configuration screen "Class Name" field.

   (3) Removing disk

   Select the disk you want to remove from [Class Configuration Disk] field, and click <Delete>.

   [Figure: Removing Disk]
